FWF strings instrument double piezo with low pass filter

  •
  • id:
    41927
  • sku:
    FWF-MG2
  • brandname:
    FWF

strings instrument double piezo with low pass filter, built-in version

First of all we would like to remind you that the installation of this system should best be done by a professional luthier or guitar specialist.

The MG2 is a double piezo pickup for the amplification of all stringed instruments. It is a passive pickup which means it doesn’t need batteries to work.

To install the system you will have to place the two piezos on each side of the bridge under the top of the instrument. We recommend to use neoprene glue to fix it.

For the jack plug, use a 10mm bore and make a hole in the side of the instrument at the desired spot.

Use the bolt to tighten it in the hole.

The MG2 has a low pass filter which can be adjusted with a flat screw driver at the back of the femal jack plug.
